components DC - 100 GHz
RF & Microwave PCB Laminates
- Lowest-Loss PCB laminates
- Lowest-loss Copper
- EZ-IO: low loss & drills like FR4
- Bond Plies / Prepregs material
LDMOS & GaN Transistors for HPA’s applications
- Mobile Broadband, Aerospace and Defense (Pulsed Radar)
- UHF Broadcast, Extremely Rugged, General Purpose - Wideband, ISM
.jpg/:/cr=t:0%25,l:0%25,w:100%25,h:100%25/rs=w:388,cg:true)
Ceramic Caps: Chip, Single, & Stacked
- Power & Microwave Capacitors from DC-100 GHz, up to T=500 C
- Stack, Multilayer, High-Voltage
- NPO Caps for High Q
Oscillators: OCXO, TCXO, SAW, VCXO, PLL & Modules to 10 GHz
- Frequency Reference Units, Rubidium & Cesium Clocks
- Military, Avionics, Space (to 50 kRad), Radar & EW applications
- Low Phase Noise, Lower Tuning Sensitivity & Lower Power Consumption
Hi-Rel, Low-phase-noise Crystal Oscillators (AS9100 & ISO 9001)
- Space, Military (MIL-PRF-55310 QPL), & Avionics Applications
- Oscillators: XO, TCXO, VCXO, OCXO, MCXO & SAW’s
Millimeter-Wave MMIC Component, Radio & Satellite Solutions
- Front End Modules in GaN & InP
- LNA’s, Power Amps & Switches
- 5G/6G Wireless Comm’s
Components for SatCom, Defense, T&M Applications
- Filters, Multiplexers, Couplers, Combiners,
- Antennas, & mmWave Packages
- Improve performance, reduce size, weight, & lower cost
- Uses PolyStrata® Technology
EMC, Florida RF Labs, Lorch, Trak
- Resistive Products -- Attenuators, Terminations & Resistors
- Coax Cable Assemblies
- RF/Microwave Filters
- Waveguide Circulators/Isolators
.png/:/cr=t:16.22%25,l:0%25,w:100%25,h:70%25/rs=w:388,h:194,cg:true)
Inductors & Transformers for RF & Power applications
- Parameters: Power: mW to 3 KVA
- Current: mA to 100+ amps
- Size: 0603 to >3 cubic feet
SUB-SYSTEMS, components and SERVICES DC– 67 GHz
Waveguide, Assemblies up to 50 GHz
- Rotary Switches & Rotary Joints
- Adapters, Dividers, Couplers, Magic Tees, Flanges, Attenuators,
- Comparator & Pressure Windows
Waveguide Components
- Ka-Band Satcom, Space-Qualified and Subsystems
- Adapters, Attenuators, Couplers, Isolators/Circulators, Power
- Power dividers & Combiners, Termination, Tees, Windows & custom solutions
RF/Microwave Comp., Subsystem
-Amps (LNA's)
- Couplers, Power Dividers, Attenuators, Terminations, Phase Shifters, Detectors, Adapters
- Mixers, Multipliers, Frequency sources
- Pin Diode Limiters & Switches
- SatCom & Space solutions
- Fiber Optic and Custom Solutions
Silicon Dioxide (SiO2) Dielectric Cable Assemblies
- 50 Ohm Cable to 65 GHz
- Diameter: .09, .141, .200, & .275
Hermetic sealed, >900OC
- Phase matched assemblies and Custom Bends
Traveling-Wave Tubes
- Traveling-Wave Tubes (TWT)
- TWT Amplifiers (TWTA)
- MHz to GHz, Watts to Mega Watts
- For Space, Defense, High-Rel Applications
